TLV3502AIDCNR: Overview, Features and Applications
In the ever-evolving landscape of electronics, precision and reliability are non-negotiable. Texas Instrument's TLV3502AIDCNR emerges as a beacon of innovation, pushing the boundaries of what's possible in General Purpose Amplifiers. Let’s unravel the intricacies of this exceptional electronic component.
TLV3502AIDCNR Overview
The TLV3502AIDCNR is a Dual General Purpose Amplifier, boasting Rail-to-Rail Input/Output capabilities. This means it operates seamlessly within the voltage range of ±2.75V to 5.5V, making it an ideal choice for a myriad of applications.
Key Features
1. Precision at Its Core
l Rail-to-Rail Operation: The TLV3502AIDCNR ensures optimal signal integrity with its Rail-to-Rail Input/Output design.
l CMOS Technology: Leveraging advanced CMOS process technology, this amplifier delivers precision without compromise.
2. Performance Metrics
l Low Input Offset Voltage: A mere 1.6mV at 5V ensures minimal distortion, enhancing the amplifier's accuracy.
l High Gain Bandwidth Product: With a typical Gain Bandwidth Product of 5MHz, expect superior performance across a broad frequency spectrum.
l Extended Temperature Range: Operating flawlessly from -40°C to 125°C, the TLV3502AIDCNR thrives in diverse environmental conditions.
Specifications
Let's delve into the technical specifications that make the TLV3502AIDCNR an industry standout:
Type | Parameter |
Type | General Purpose Amplifier |
Manufacturer Type | General Purpose Amplifier |
Number of Channels per Chip | 2 |
Rail to Rail | Rail to Rail Input/Output |
Process Technology | CMOS |
Output Type | CMOS |
Maximum Input Offset Voltage (mV) | 1.6@5V |
Minimum Single Supply Voltage (V) | 1.8 |
Maximum Single Supply Voltage (V) | 5.5 |
Minimum Dual Supply Voltage (V) | ±0.9 |
Maximum Dual Supply Voltage (V) | ±2.75 |
Maximum Input Offset Current (uA) | 0.000001(Typ)@5.5V |
Typical Input Bias Current (uA) | 0.000002@5.5V |
Maximum Quiescent Current (mA) | 0.9@5.5V |
Power Supply Type | Single|Dual |
Typical Slew Rate (V/us) | 15@5.5V |
Typical Input Noise Voltage Density (nV/rtHz) | 20@5V |
Typical Voltage Gain (dB) | 130 |
Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.018@5.5V |
Minimum PSRR (dB) | 97.72(Typ) |
Minimum CMRR (dB) | 62 |
Minimum CMRR Range (dB) | 60 to 65 |
Typical Gain Bandwidth Product (MHz) | 5 |
Typical Settling Time (ns) | 1000 |
Shut Down Support | No |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Supplier Temperature Grade | Extended |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 0.95(Max) |
Package Width | 3.1(Max) |
Package Length | 3.1(Max) |
PCB changed | 10 |
Standard Package Name | SO |
Supplier Package | VSSOP |
Pin Count | 10 |
Lead Shape | Gull-wing |
Applications
The TLV3502AIDCNR finds its place in various applications, including:
l Signal Conditioning: Amplify weak signals without compromising accuracy.
l Sensor Interfaces: Ensure precise data acquisition with the TLV3502AIDCNR at the heart of your sensor interfaces.
l Control Systems: Experience enhanced control system performance with the amplifier's low input offset voltage.
TLV3502AIDCNR’s Manufacturer
Texas Instruments, a global semiconductor and electronics company, stands as a pioneering force in the technological landscape. Renowned for its commitment to innovation and excellence, Texas Instruments has played a pivotal role in shaping the electronics industry for decades. With a diverse portfolio spanning analog and digital technologies, power management, and embedded processing, Texas Instruments continues to empower engineers, designers, and innovators worldwide.
Conclusion
In the realm of General Purpose Amplifiers, the TLV3502AIDCNR stands tall, offering a perfect blend of precision, versatility, and reliability.
