MC7815BTG: Features, Specifications & More
In this comprehensive article, we'll walk you through the definition, key features, specifications, applications, and the manufacturer's insights into this powerhouse component.
MC7815BTG's Overview
The Onsemi MC7815BTG is a standard regulator, a vital component in electronics, ensuring a stable and reliable power supply. With a positive polarity, it offers a fixed output voltage of 15V and a maximum output current of 1A.
Key Features
Let's delve into its standout features:
· With an impressive accuracy of ±4%, the MC7815BTG ensures your voltage requirements are met with unparalleled precision.
· Crafted with bipolar process technology, this regulator embodies durability and reliability, making it a cornerstone for various electronic applications.
· Current limit, safe area protection, short circuit protection, and thermal shutdown protection ensure the safety of your circuits, even in challenging conditions.
Specifications
Let's delve deeper into the specifications that set the MC7815BTG apart:
Type | Parameter |
Type | Standard |
Number of Outputs | 1 |
Polarity | Positive |
Accuracy (%) | ±4 |
Process Technology | Bipolar |
Output Type | Fixed |
Output Voltage (V) | 15 |
Maximum Output Current (A) | 1(Min) |
Minimum Input Voltage (V) | 17 |
Maximum Input Voltage (V) | 35 |
Line Regulation | 300mV |
Load Regulation | 300mV |
Maximum Quiescent Current (mA) | 8 |
Junction to Ambient | 65°C/W |
Junction to Case | 5°C/W |
Special Features | Current Limit|Safe Area Protection|Short Circuit Protection|Thermal Shutdown Protection |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Packaging | Tube |
Mounting | Through Hole |
Package Height | 9.28(Max) |
Package Width | 4.82(Max) |
Package Length | 10.28(Max) |
PCB changed | 3 |
Tab | Tab |
Standard Package Name | TO-220 |
Supplier Package | TO-220 |
Pin Count | 3 |
Lead Shape | Through Hole |
Applications
The MC7815BTG finds its application across a spectrum of electronic projects, including but not limited to:
· Power supply units: The MC7815BTG excels in powering a wide array of electronic devices, ensuring a stable and regulated 15V output for optimal performance in power supply units.
· Voltage regulators: As a fixed-output voltage regulator, the MC7815BTG plays a crucial role in maintaining a constant 15V supply, making it ideal for voltage regulation applications where precision is paramount.
· Industrial automation: In the realm of industrial automation, the MC7815BTG provides reliable power, contributing to the seamless operation of machinery and systems by ensuring consistent voltage levels.
· Consumer electronics: From gadgets to household appliances, the MC7815BTG finds its place in consumer electronics, guaranteeing a dependable power source for various devices, enhancing their functionality and longevity.
MC7815BTG's Manufacturer
ON Semiconductor, stylized in lowercase as "onsemi", stands at the forefront of technological innovation, driving advancements that power intelligent and energy-efficient systems worldwide. With a commitment to delivering cutting-edge solutions, ON Semiconductor provides a comprehensive portfolio of semiconductor products, spanning power management, analog, sensor, and connectivity solutions. Leveraging a legacy of over 20 years, the company has solidified its position as a trusted partner for industries ranging from automotive and industrial to consumer electronics and healthcare.
Conclusion
In conclusion, the ON Semiconductor MC7815BTG isn't merely a regulator; it stands as a transformative force in the realm of electronics. Trust in the precision, reliability, and innovation encapsulated in the MC7815BTG for a seamless electronic experience. Embrace the power it offers, and let creations thrive with the stability they deserve.
