MC908JK3ECDWE: Features, Specifications & More
In this comprehensive article, we will unravel the mysteries surrounding Freescale Semiconductor's MC908JK3ECDWE – a 8-bit microcontroller (MCU) that's taking the electronics industry by storm. Let's delve into its definition, key features, specifications, applications, and a closer look at its manufacturer.
MC908JK3ECDWE's Overview
The MC908JK3ECDWE belongs to the HC08 family, showcasing a Complex Instruction Set Computing (CISC) architecture. As a microcontroller, it forms the core of devices in various electronic applications. This 8-bit powerhouse operates at a maximum CPU frequency of 8MHz, making it a robust choice for tasks that demand swift processing.
Key Features
· The MC908JK3ECDWE offers 4KB of Flash memory, providing programmers with ample space to create intricate applications.
· Compact yet powerful, this 8-bit MCU operates at a swift 8MHz clock rate, proving that performance doesn't compromise size.
· With 15 I/O ports and 2 PWM-enabled timers, developers can easily design sophisticated control systems and interfaces.
· The single ADC supporting 12 channels and 8-bit resolution ensures accurate analog-to-digital conversions for a range of sensor applications.
· While lacking some built-in interfaces, the MC908JK3ECDWE provides a solid base for applications not requiring UART, SPI, or I2C protocols.
Specifications
Now, let's delve into the technical specifications that make the MC908JK3ECDWE a standout choice for electronic projects:
Type | Parameter |
Family Name | HC08 |
Instruction Set Architecture | CISC |
Device Core | HC08 |
Core Architecture | HC08 |
Maximum CPU Frequency (MHz) | 8 |
Maximum Clock Rate (MHz) | 8 |
Data Bus Width (bit) | 8 |
Program Memory Type | Flash |
Program Memory Size | 4KB |
RAM Size | 128B |
Maximum Expanded Memory Size | 64KB |
Programmability | Yes |
Number of I/Os | 15 |
No. of Timers | 2 |
PWM | 2 |
Number of ADCs | Single |
ADC Channels | 12 |
ADC Resolution (bit) | 8 |
USART | 0 |
UART | 0 |
USB | 0 |
SPI | 0 |
I2C | 0 |
I2S | 0 |
CAN | 0 |
Ethernet | 0 |
Analog Comparators | 2 |
Parallel Master Port | No |
Real Time Clock | No |
Minimum Operating Supply Voltage (V) | 2.7 |
Typical Operating Supply Voltage (V) | 3.3|5 |
Maximum Operating Supply Voltage (V) | 5.5 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Supplier Temperature Grade | Industrial |
Packaging | Tube |
Mounting | Surface Mount |
Package Height | 2.4(Max) |
Package Width | 7.6(Max) |
Package Length | 12.95(Max) |
PCB changed | 20 |
Standard Package Name | SO |
Supplier Package | SOIC W |
Pin Count | 20 |
Lead Shape | Gull-wing |
Applications
The MC908JK3ECDWE finds its home in a myriad of applications, thanks to its robust features and adaptability:
· Embedded Systems: Ideal for powering embedded systems requiring reliable and efficient control.
· Automotive Electronics: With its industrial-grade temperature tolerance, it's a perfect fit for automotive applications.
· Consumer Electronics: From smart devices to home automation, this MCU adds intelligence to various consumer gadgets.
MC908JK3ECDWE's Manufacturer
Freescale Semiconductor, Inc., now seamlessly integrated into NXP Semiconductors, stands as a pioneering force in the semiconductor industry. Renowned for its cutting-edge technologies, Freescale Semiconductor played a pivotal role in shaping the landscape of embedded solutions and microcontrollers. With a commitment to innovation and a rich legacy, the company has consistently delivered high-performance semiconductor solutions, catering to a diverse range of industries. Following its merger with NXP Semiconductors, a global semiconductor powerhouse, the legacy of Freescale continues to thrive, fostering advancements in automotive, industrial, and IoT applications.
Conclusion
In conclusion, the MC908JK3ECDWE stands tall as a testament to Freescale Semiconductor's commitment to pushing the boundaries of innovation. From its compact design to versatile applications, this 8-bit HC08 CISC MCU is a game-charger in the world of electronics
