Toshiba Auto Power MOSFETs: Unleash Ultra-Performance

August 17, 2023 — Toshiba, the leading innovator in electronic components, proudly announces the launch of two cutting-edge 40V N-channel Power MOSFETs designed specifically for the automotive sector. The groundbreaking XPJR6604PB and XPJ1R004PB models are packaged in Toshiba's advanced S-TOGLTM format, featuring the powerful U-MOS IX-H process technology. Both models are now readily available for bulk orders.

Designed to meet the rigorous demands of advanced safety applications like autonomous driving systems, these MOSFETs ensure unparalleled reliability through redundant design. By integrating more components, these MOSFETs offer enhanced safety while requiring less assembly space. This breakthrough enables automotive equipment to be more compact while maintaining high-current capabilities.

The XPJR6604PB and XPJ1R004PB come housed in Toshiba's state-of-the-art S-TOGLTM package (7.0mm×8.44mm[1]). This unique package design integrates source pin connections with external pins, reducing packaging resistance and enhancing efficiency.

Compared to traditional packages with similar thermal resistance, Toshiba's S-TOGLTM package, combined with the U-MOS IX-H process, yields an impressive 11% reduction in on-state resistance. Moreover, this innovative package reduces required surface area by approximately 55%, allowing for more efficient design layouts. These MOSFETs offer a high drain current rating of 200A, surpassing similar-sized products and facilitating high-current applications. Additionally, the compact S-TOGLTM design aids in heat dissipation and contributes to efficient space utilization.

Reliability is paramount in extreme temperature environments, and Toshiba's S-TOGLTM package addresses this concern with its gull-wing pins that reduce stress on solder joints, ensuring consistent performance over time.

For applications needing parallel device connections, Toshiba supports sorting these products by gate threshold voltage groups, minimizing performance deviations and ensuring consistent functionality.

Toshiba is committed to expanding its line of power semiconductor products, providing user-friendly, high-performance solutions that contribute to carbon neutrality.

· Applications:

- Automotive Innovations: Inverters, Semiconductor Relays, Load Switches, Motor Drivers, and more.

· Features:

- Advanced S-TOGLTM Package: Compact dimensions of 7.0mm×8.44mm (typical).

- Impressive Drain Current Ratings:

- XPJR6604PB: Up to 200A

- XPJ1R004PB: Up to 160A

- Certified to AEC-Q101 standards.

- IATF 16949/PPAP Compliant[4].

- Low On-State Resistance:

- XPJR6604PB: Only 0.53mΩ (typical) (VGS = 10V).

- XPJ1R004PB: Only 0.8mΩ (typical) (VGS = 10V).
