ADS7924IRTER: Features, Specifications & More
In the dynamic landscape of electronics, the Texas Instruments ADS7924IRTER stands out as a pinnacle of precision and innovation. In this comprehensive article, we'll unravel the definition, key features, specifications, applications, and the esteemed manufacturer behind the ADS7924IRTER.
ADS7924IRTER's Overview
The Texas Instruments ADS7924IRTER is a state-of-the-art 4-channel single ADC (Analog-to-Digital Converter), featuring a SAR (Successive Approximation Register) architecture. This compact powerhouse boasts a 12-bit resolution and an impressive 100ksps (kilo samples per second) sampling rate, making it a versatile solution for a myriad of applications.
Key Features
· Versatile and adaptable, the ADS7924IRTER serves as a go-to solution for a wide range of electronic applications.
· With SAR architecture, this ADC ensures high precision and accuracy in signal conversion, ideal for demanding electronic systems.
· Delivering detailed and accurate digital representations, the ADS7924IRTER's 12-bit resolution is crucial for maintaining signal integrity.
· Simultaneously converting multiple analog signals, the ADC's four input channels enhance its utility in various scenarios.
· Utilizing the I2C protocol, the ADS7924IRTER facilitates seamless communication with other digital components in your electronic system.
Specifications
Let's delve deeper into the specifications that set the ADS7924IRTER apart:
Type | Parameter |
Converter Type | General Purpose |
Architecture | SAR |
Resolution | 12bit |
Number of ADCs | 1 |
Number of Input Channels | 4 |
Sampling Rate | 100ksps |
Digital Interface Type | Serial (2-Wire, I2C) |
Input Type | Voltage |
Input Signal Type | Single-Ended |
Voltage Reference | Supply |
Polarity of Input Voltage | Unipolar |
Voltage Supply Source | Analog and Digital |
Input Voltage | 5V |
Integral Nonlinearity Error | ±1.5LSB |
Full Scale Error | ±0.2%FSR |
No Missing Codes (bit) | 12 |
Sample and Hold | No |
Single-Ended Input | Yes |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Packaging | Tape and Reel |
Supplier Temperature Grade | Industrial |
Mounting | Surface Mount |
Package Height | 0.75(Max) |
Package Width | 3.15(Max) |
Package Length | 3.15(Max) |
PCB changed | 16 |
Standard Package Name | QFN |
Supplier Package | WQFN EP |
Pin Count | 16 |
Lead Shape | No Lead |
Applications
The Texas Instruments ADS7924IRTER finds its application in a plethora of scenarios:
· Industrial Automation: Precise analog-to-digital conversion in industrial sensors and monitoring systems.
· Medical Devices: Ensuring accurate signal processing in medical imaging equipment and patient monitoring devices.
· Consumer Electronics: Powering high-performance audio equipment, ensuring fidelity in sound reproduction.
· Automotive Systems: Contributing to efficient data acquisition in automotive control systems.
ADS7924IRTER's Manufacturer
Texas Instruments (TI), established in 1930, is a global leader in semiconductor and technology solutions, known for its pioneering contributions to the electronics industry. Specializing in the design and manufacture of analog and digital circuits, microcontrollers, and processors, TI has played a pivotal role in shaping technological advancements across diverse sectors, including industrial, automotive, consumer electronics, and communication.
Conclusion
In conclusion, the Texas Instruments ADS7924IRTER is a game-changer in the realm of Analog-to-Digital Converters. With its advanced features, robust specifications, and diverse applications, it caters to the needs of electronic enthusiasts, engineers, and industry professionals alike.
