TBA 2-1212: Features, Specs & More
Among the electronic components, power modules stand out as crucial elements that dictate the efficiency and reliability of electronic devices. One such standout in the realm of power modules is the TRACO POWER TBA 2-1212, a compact yet robust DC-DC module designed to meet the demands of modern electronic applications. In this comprehensive article, we'll delve into the intricacies of the TBA 2-1212, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
TBA 2-1212's Overview
At its core, the TRACO POWER TBA 2-1212 is a module DC-DC converter with a 12V input and a single 12V output. This SIP (Single Inline Package) module is engineered to provide efficient power conversion while ensuring isolation between input and output circuits. With its compact design and exceptional performance, the TBA 2-1212 is a go-to solution for applications requiring reliable power delivery in constrained spaces.
Key Features
Let's delve into the standout features that make the TBA 2-1212 a standout in the world of electronics:
· With its isolated design, the TBA 2-1212 ensures that input and output circuits remain electrically separated, minimizing the risk of electrical faults and enhancing system safety.
· Measuring just 10.2mm in height, 7.6mm in width, and 19.55mm in length, this module offers a compact footprint, making it ideal for applications where space is at a premium.
· The TBA 2-1212 accommodates input voltages ranging from 10.8V to 13.2V, providing flexibility and compatibility with a variety of power sources.
· With an efficiency rating of 82%, the TBA 2-1212 minimizes power loss during conversion, resulting in optimal energy utilization and reduced operating costs.
· From frigid environments to sweltering conditions, this module operates reliably across a broad temperature spectrum, ranging from -40°C to 90°C.
· Built to withstand the rigors of industrial and automotive applications, the TBA 2-1212 boasts a rugged construction that ensures durability and longevity.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the TBA 2-1212:
Type | Parameter |
Isolation | Isolated |
Number of Outputs | 1 |
Minimum Input Voltage (V) | 10.8 |
Typical Input Voltage (V) | 12 |
Maximum Input Voltage (V) | 13.2 |
Output Voltage (V) | 12 |
Output Current (A) | 0.165 |
Output Power (W) | 2 |
Minimum Isolation Voltage | 1500VDC |
Input/Output Type | DC/DC |
Switching Frequency (kHz) | 200 |
Switching Regulator | Yes |
Line Regulation | 1.5% |
Efficiency (%) | 82(Typ) |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 90 |
Product Weight (g) | 2.8 |
Output Type | Fixed |
Mounting | Through Hole |
Package Height | 10.2 |
Package Width | 7.6 |
Package Length | 19.55 |
PCB changed | 4 |
Standard Package Name | SIP |
Supplier Package | SIP Module |
Pin Count | 4 |
Applications
The versatility of the TRACO POWER TBA 2-1212 extends across various industries and applications, including:
· Industrial Automation: From motor control systems to factory automation equipment, the TBA 2-1212 ensures reliable power delivery, enabling seamless operation in industrial settings.
· Telecommunications: In telecommunications infrastructure, where space is often limited, this compact module provides efficient power conversion for networking equipment and communication devices.
· Automotive Electronics: With its wide operating temperature range and robust design, the TBA 2-1212 is well-suited for automotive applications, including vehicle power management systems and onboard electronics.
· Consumer Electronics: From handheld devices to home appliances, the TBA 2-1212 offers a reliable power source for a wide range of consumer electronics products, ensuring optimal performance and longevity.
TBA 2-1212's Manufacturer
Founded in 1944, TRACO Power is a manufacturer of power supply devices seated in Baar, Switzerland with more than 35 years of experience, specialising in the design and manufacturing of high quality DC/DC and AC/DC converters which are being used in such industries as automation, IT, transportation, medicine, and renewable energy.
Conclusion
In conclusion, the TRACO POWER TBA 2-1212 emerges as a standout solution for applications that demand efficiency, reliability, and compactness in power conversion. With its robust features, wide-ranging capabilities, and the backing of a trusted manufacturer, this module sets the standard for excellence in the realm of DC-DC converters.
