AD7266BSUZ-REEL7: Features, Specs & More
In the ever-evolving world of electronics, the ADI AD7266BSUZ-REEL7 stands as a premier choice for designers needing a high-performance analog-to-digital converter (ADC). In this comprehensive article, we'll delve into the intricacies of the AD7266BSUZ-REEL7, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
AD7266BSUZ-REEL7's Manufacturer
AD7266BSUZ-REEL7's Overview
The AD7266BSUZ-REEL7 is a high-performance, general-purpose 12-channel dual ADC (Analog-to-Digital Converter) based on SAR (Successive Approximation Register) architecture. This device is designed to provide accurate digital representation of analog signals, making it an ideal choice for a variety of applications in the electronics field. With a 12-bit resolution and a sampling rate of 2Msps, it ensures precise and efficient signal conversion.
Key Features
Let's delve into the standout features that make the AD7266BSUZ-REEL7 a standout in the world of electronics:
· The AD7266BSUZ-REEL7 offers precise 12-bit resolution and a high 2Msps sampling rate for accurate data acquisition.
· It features 12 input channels, supporting single-ended, pseudo-differential, and differential signal types for versatile application use.
· This ADC operates with both internal and external voltage references, providing flexibility in system design.
· Designed for efficiency, the AD7266BSUZ-REEL7 has a maximum power dissipation of just 33.6mW, ideal for low-power applications.
· With a maximum power dissipation of just 33.6 mW, it is energy efficient, making it suitable for battery-powered and low-power applications.
· Its serial digital interface is compatible with SPI, QSPI, and Microwire, ensuring easy integration with various microcontrollers and processors.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the AD7266BSUZ-REEL7:
Type | Parameter |
Converter Type | General Purpose |
Architecture | SAR |
Resolution | 12bit |
Number of ADCs | 2 |
Number of Input Channels | 12|6 |
Sampling Rate | 2Msps |
Digital Interface Type | Serial (SPI, QSPI, Microwire) |
Input Type | Voltage |
Input Signal Type | Single-Ended|Pseudo-Differential|Differential |
Voltage Reference | Internal|External |
Polarity of Input Voltage | Unipolar |
Voltage Supply Source | Analog and Digital |
Input Voltage | 2.5V/5V |
Maximum Power Dissipation (mW) | 33.6 |
Integral Nonlinearity Error | ±1.5LSB |
Full Scale Error | ±2.5LSB |
Signal to Noise Ratio | 71dB(Min) |
No Missing Codes (bit) | 12 |
Sample and Hold | Yes |
Single-Ended Input | Yes |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 1 |
Package Width | 7 |
Package Length | 7 |
PCB changed | 32 |
Standard Package Name | QFP |
Supplier Package | TQFP |
Pin Count | 32 |
Lead Shape | Gull-wing |
* AD7266BSUZ-REEL7's Datasheet
Applications
The AD7266BSUZ-REEL7's robust feature set and flexible architecture make it suitable for a wide range of applications, including but not limited to:
· Industrial Automation: Its high sampling rate and precision make it ideal for monitoring and controlling industrial processes.
· Medical Devices: The ADC's accuracy and low power consumption are critical for medical instrumentation that requires reliable and precise measurements.
· Automotive Systems: It can be used in various automotive applications, such as engine control units and infotainment systems, where rapid and accurate data conversion is essential.
· Consumer Electronics: Devices such as digital cameras, audio equipment, and gaming consoles can benefit from its high performance and efficiency.
· Communication Systems: The ADC's ability to handle multiple input types and its fast sampling rate make it suitable for modern communication systems, including wireless and wired networks.
AD7266BSUZ-REEL7's Manufacturer
Analog Devices, Inc. (ADI) stands as a global leader in analog and mixed-signal technology, pioneering transformative solutions since 1965. Renowned for innovation, ADI's diverse portfolio of high-performance integrated circuits spans precision amplifiers, data converters, sensors, and digital signal processing.
Conclusion
The ADI AD7266BSUZ-REEL7 is a standout choice for engineers and designers looking for a high-speed, high-precision ADC. Its versatile input options, robust performance, and low power consumption make it ideal for numerous applications, from industrial automation to consumer electronics.
