LAN9500A-ABZJ: Features, Specs & More
In the world of embedded systems and networking, USB to Ethernet controllers play a pivotal role. One such notable product is the Microchip LAN9500A-ABZJ, a highly efficient USB 2.0 to 10/100 Ethernet controller. In this comprehensive article, we'll delve into the intricacies of the LAN9500A-ABZJ, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
LAN9500A-ABZJ's Overview
The LAN9500A-ABZJ is a USB 2.0 to 10/100 Ethernet Controller produced by Microchip Technology. This controller acts as an interface between a USB port and Ethernet networks, offering a seamless connection for a range of embedded applications. It supports both Full Speed and High Speed USB 2.0 protocols, making it an ideal solution for devices requiring reliable data transfer at up to 100 Mbps.
Key Features
Let's delve into the standout features that make the LAN9500A-ABZJ a standout in the world of electronics:
· Supports USB 2.0, offering an easy integration between USB and Ethernet networks.
· Operates at both Full Speed (12 Mbps) and High Speed (480 Mbps), ensuring efficient data transmission.
· With a maximum data rate of 100 Mbps, this controller ensures fast and stable Ethernet connectivity.
· It operates within a range of 3.0V to 3.6V, with a typical operating voltage of 3.3V.
· Available in a 56-Pin VQFN EP package, it is designed for surface mount and compact applications.
· With an operational temperature range of 0°C to 70°C, the LAN9500A-ABZJ is suitable for a variety of industrial and commercial environments.
· With a typical supply current of 46mA, the device is energy-efficient, a key consideration for embedded systems.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the LAN9500A-ABZJ:
Type | Parameter |
Type | USB 2.0 to 10/100 Ethernet Controller |
USB Transceiver | Yes |
USB Speed Type | Full Speed|High Speed |
Maximum Data Rate (MBps) | 100 |
Maximum Operating Frequency (MHz) | 25 |
Protocols Supported | USB 2.0 |
Interface Type | USB |
Minimum Operating Supply Voltage (V) | 3 |
Maximum Operating Supply Voltage (V) | 3.6 |
Typical Operating Supply Voltage (V) | 3.3 |
Typical Supply Current (mA) | 46 |
Minimum Operating Temperature (°C) | 0 |
Maximum Operating Temperature (°C) | 70 |
Supplier Temperature Grade | Commercial |
Packaging | Tray |
Mounting | Surface Mount |
Package Height | 0.83 |
Package Width | 8 |
Package Length | 8 |
PCB changed | 56 |
Standard Package Name | QFN |
Supplier Package | VQFN EP |
Pin Count | 56 |
Lead Shape | No Lead |
Applications
The LAN9500A-ABZJ is incredibly versatile, making it suitable for a variety of applications in several industries. Some of the key areas where this controller is commonly used include:
· Embedded Systems: Ideal for systems requiring network connectivity without the complexity of adding dedicated Ethernet ports.
· Set-Top Boxes & PVRs: Used in set-top boxes and personal video recorders (PVRs) to connect to Ethernet networks for streaming and downloads.
· Consumer Electronics Devices (CE Devices): Common in networking consumer electronics, offering reliable connectivity for smart devices.
· Networked Printers: Provides the necessary bridge between USB ports and Ethernet networks for printers that need network access.
· USB Port Replicators: Expands USB connectivity in devices like docking stations.
· Standalone USB to Ethernet Dongles: Enables USB-based computers or devices to access Ethernet networks through a compact USB dongle.
· Test Instrumentation: For testing devices that need precise Ethernet connections, the LAN9500A-ABZJ is an excellent choice.
· Industrial Applications: Supports networking in industrial setups requiring robust and compact connectivity.
LAN9500A-ABZJ's Manufacturer
Microchip Technology, a global leader in the semiconductor industry, stands at the forefront of innovation, consistently pushing the boundaries of technology to create solutions that power the interconnected world. With a rich history dating back to 1989, Microchip has become synonymous with cutting-edge microcontroller and analog products. Renowned for its commitment to quality, reliability, and customer satisfaction, the company offers a comprehensive portfolio of integrated circuits and embedded solutions. Microchip's diverse range of products caters to a wide array of industries, including automotive, industrial, consumer electronics, and healthcare.
Conclusion
The LAN9500A-ABZJ USB 2.0 to 10/100 Ethernet Controller from Microchip is an ideal choice for a wide range of applications due to its reliable performance, low power consumption, and compact form factor. For those looking to integrate USB to Ethernet functionality into their devices, the LAN9500A-ABZJ is a highly recommended solution that balances cost and performance, making it a go-to choice for engineers and designers in various fields.
