XTR116UA/2K5: Features, Specs & More
In the world of industrial electronics, reliable sensor interfaces are crucial for efficient control and monitoring systems. The TI XTR116UA/2K5 is a high-performance 2-wire sensor transmitter designed for industrial applications requiring precise analog-to-digital conversion. With its robust features, it is widely used in process control, test systems, and a variety of other industrial setups. In this comprehensive article, we'll delve into the intricacies of the XTR116UA/2K5, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
XTR116UA/2K5's Overview
The TI XTR116UA/2K5 is a sensor transmitter that provides a simple, reliable interface for connecting sensors to industrial control systems. The device uses a 2-wire interface and converts an analog input signal into a digital output signal that can be read by various systems. It operates within a wide range of supply voltages (from 7.5V to 36V), making it adaptable for a variety of environments, including industrial process control, test systems, and other high-precision applications.
Key Features
Let's delve into the standout features that make the XTR116UA/2K5 a standout in the world of electronics:
· A 2-wire configuration makes it easier to integrate into existing systems, reducing the need for extra wiring.
· With a minimum operating voltage of 7.5V and a maximum of 36V, this device offers flexibility for various industrial power requirements.
· Capable of operating in extreme conditions, the XTR116UA/2K5 works effectively between -40°C to 85°C.
· Designed to meet the needs of industrial environments, it is built to withstand the rigors of everyday use.
· The device comes in an 8-pin SOIC package that supports surface mounting for space-saving installation.
· The XTR116UA/2K5 works seamlessly with HART modems, ensuring effective communication in process control systems.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the XTR116UA/2K5:
Type | Parameter |
Sensor Type | Sensor Transmitter |
Interface Type | 2-Wire |
Input Type | Analog |
Output Type | Digital |
Minimum Operating Supply Voltage (V) | 7.5 |
Maximum Operating Supply Voltage (V) | 36 |
Typical Operating Supply Voltage (V) | 24 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Supplier Temperature Grade | Industrial |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 1.5(Max) |
Package Width | 3.98(Max) |
Package Length | 5(Max) |
PCB changed | 8 |
Standard Package Name | SO |
Supplier Package | SOIC |
Pin Count | 8 |
Lead Shape | Gull-wing |
Applications
The versatility of the TI XTR116UA/2K5 shines through in its wide range of applications. Below are some of the key use cases:
· Industrial Process Control: The XTR116UA/2K5 is ideal for controlling and monitoring industrial processes, where precision and reliability are crucial.
· 2-Wire Current Loop Systems: It is commonly used in 4-20 mA current loop systems, which are essential in many industrial environments for transmitting analog signals over long distances.
· Smart Transmitters: This device is compatible with smart transmitter setups, offering seamless integration with advanced process control systems.
· Test Systems: The XTR116UA/2K5 is also widely used in test systems, where its analog-to-digital conversion is vital for accurate measurements.
· HART Modem Compatibility: The XTR116UA/2K5 is fully compatible with HART modems, making it ideal for smart sensor applications that require digital communication.
· Current and Voltage Amplification: It serves as both a current amplifier and a voltage-to-current amplifier, providing versatility in various industrial setups.
XTR116UA/2K5's Manufacturer
Texas Instruments (TI), established in 1930, is a global leader in semiconductor and technology solutions, known for its pioneering contributions to the electronics industry. Specializing in the design and manufacture of analog and digital circuits, microcontrollers, and processors, TI has played a pivotal role in shaping technological advancements across diverse sectors, including industrial, automotive, consumer electronics, and communication.
Conclusion
The TI XTR116UA/2K5 sensor transmitter is an excellent choice for industrial process control, test systems, and smart transmitter applications. With its broad operating voltage, wide temperature range, and compatibility with HART modems, it provides a reliable and efficient solution for industrial automation.
