NCV2931AD-5.0R2G: Features, Specs & More
In the world of electronic components, voltage regulators play a critical role in ensuring that power is supplied consistently and reliably to different devices. The Onsemi NCV2931AD-5.0R2G, an LDO (Low Dropout) regulator, is designed specifically for automotive and battery-powered applications, providing a stable 5V output. In this comprehensive article, we'll delve into the intricacies of the NCV2931AD-5.0R2G, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
NCV2931AD-5.0R2G's Manufacturer
NCV2931AD-5.0R2G's Overview
The NCV2931AD-5.0R2G is a Low Dropout (LDO) Regulator designed to provide a stable 5V output with a maximum current of 0.1A. It's engineered for automotive applications, meeting the AEC-Q100 qualification standards, ensuring durability and reliability even under challenging conditions. This voltage regulator is ideal for battery-powered consumer electronics, handheld instruments, and automotive systems that require a compact and reliable power solution.
Key Features
Let's delve into the standout features that make the NCV2931AD-5.0R2G a standout in the world of electronics:
· The NCV2931AD-5.0R2G delivers a fixed 5V output, making it ideal for systems that require a constant voltage.
· With an accuracy of ±3.8%, this LDO regulator ensures precise voltage regulation, which is essential for sensitive electronic components in automotive and consumer products.
· The regulator's dropout voltage is extremely low—just 0.2V at 10mA and 0.6V at 100mA, making it perfect for low-voltage applications where efficiency is key.
· The NCV2931AD-5.0R2G is designed with built-in thermal shutdown protection and current limit features to prevent overheating and excessive current draw.
· This device meets AEC-Q100 standards, making it suitable for automotive environments.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the NCV2931AD-5.0R2G:
Type | Parameter |
Type | LDO |
Number of Outputs | 1 |
Polarity | Positive |
Accuracy (%) | ±3.8 |
Output Type | Fixed |
Output Voltage (V) | 5 |
Maximum Output Current (A) | 0.1(Min) |
Minimum Input Voltage (V) | 2.5 |
Maximum Input Voltage (V) | 40 |
Maximum Dropout Voltage @ Current (V) | 0.2@10mA|0.6@100mA |
Line Regulation | 30mV |
Load Regulation | 50mV |
Junction to Ambient | 160°C/W |
Junction to Case | 25°C/W |
Special Features | Current Limit|Thermal Shutdown Protection |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Supplier Temperature Grade | Automotive |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 1.5(Max) |
Package Width | 4(Max) |
Package Length | 5(Max) |
PCB changed | 8 |
Standard Package Name | SO |
Supplier Package | SOIC N |
Pin Count | 8 |
Lead Shape | Gull-wing |
* NCV2931AD-5.0R2G's Datasheet
Applications
The NCV2931AD-5.0R2G is highly versatile and is used in a variety of applications, especially in automotive and portable electronics. Some of its most common uses include:
· Battery-Powered Consumer Products: The low dropout voltage and high efficiency make it ideal for use in devices that are battery operated, where power conservation is crucial.
· Handheld Instruments: Compact and efficient, this LDO regulator is perfect for powering handheld instruments that require a reliable 5V source.
· Cameras and Camcorders: The NCV2931AD-5.0R2G provides stable voltage, making it suitable for powering sensitive camera components and ensuring smooth operation.
NCV2931AD-5.0R2G's Manufacturer
ON Semiconductor, stylized in lowercase as "onsemi", stands at the forefront of technological innovation, driving advancements that power intelligent and energy-efficient systems worldwide. With a commitment to delivering cutting-edge solutions, ON Semiconductor provides a comprehensive portfolio of semiconductor products, spanning power management, analog, sensor, and connectivity solutions. Leveraging a legacy of over 20 years, the company has solidified its position as a trusted partner for industries ranging from automotive and industrial to consumer electronics and healthcare.
Conclusion
The Onsemi NCV2931AD-5.0R2G LDO Regulator is an essential component for engineers designing automotive, battery-powered, and consumer electronics. With its fixed 5V output, low dropout voltage, and robust protection features, it is perfectly suited for a wide range of applications, including handheld instruments and cameras. Its compliance with AEC-Q100 standards makes it particularly valuable for automotive designs, ensuring reliable performance even in harsh environments.
