LM35DZ/NOPB: Features, Specs & More
The TI LM35DZ/NOPB is a precision temperature sensor designed by Texas Instruments for reliable and accurate measurements. It delivers a direct analog output in millivolts proportional to the measured temperature, making it simple to integrate into electronics projects and professional applications. Its wide adoption in industries comes from its ease of use, cost efficiency, and consistent performance. In this comprehensive article, we'll delve into the intricacies of the LM35DZ/NOPB, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
LM35DZ/NOPB's Overview
The LM35DZ/NOPB is an analog temperature sensor IC designed to provide linear voltage output proportional to temperature. It interfaces through a 2-wire serial connection and can operate over a wide supply voltage range. This sensor is suitable for use in electronics projects that require precise environmental monitoring. Its robust design allows stable operation in standard temperature ranges from 0°C to 100°C.
Key Features
Let's delve into the standout features that make the LM35DZ/NOPB a standout in the world of electronics:
· The sensor provides an accuracy of ±0.4°C.
· It offers a consistent gain of 10mV per °C.
· The interface type is serial (2-wire).
· Its output is analog, compatible with standard ADCs.
· The operating voltage range is from 4V to 30V.
· It supports a typical operating voltage of 5V, 9V, 12V, 15V, 18V, or 24V.
· The standard package is TO-92 with bulk packaging.
· It has a 3-pin configuration for easy through-hole mounting.
· Maximum package dimensions are 5.34 mm height, 4.19 mm width, and 5.21 mm length.
· The sensor is optimized for use in various PCB designs with a pin count of three.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the LM35DZ/NOPB:
Type | Parameter |
Module/IC Classification | IC |
Accuracy | ±0.4°C |
Sensor Gain | 10mV/°C |
Interface Type | Serial (2-Wire) |
Output Type | Analog |
Minimum Operating Supply Voltage (V) | 4 |
Typical Operating Supply Voltage (V) | 5|9|12|15|18|24 |
Maximum Operating Supply Voltage (V) | 30 |
Minimum Operating Temperature (°C) | 0 |
Maximum Operating Temperature (°C) | 100 |
Packaging | Bulk |
Mounting | Through Hole |
Package Height | 5.34(Max) mm |
Package Width | 4.19(Max) mm |
Package Length | 5.21(Max) mm |
PCB changed | 3 |
Standard Package Name | TO |
Supplier Package | TO-92 |
Pin Count | 3 |
Lead Shape | Through Hole |
Applications
The LM35DZ/NOPB is widely used across multiple industries because of its simplicity and reliability. Some of its main applications include:
· Environmental monitoring systems
· HVAC equipment and thermostats
· Battery management systems
· Home appliances and consumer electronics
· Industrial process control systems
· Medical equipment requiring precise temperature monitoring
LM35DZ/NOPB's Manufacturer
Texas Instruments (TI), established in 1930, is a global leader in semiconductor and technology solutions, known for its pioneering contributions to the electronics industry. Specializing in the design and manufacture of analog and digital circuits, microcontrollers, and processors, TI has played a pivotal role in shaping technological advancements across diverse sectors, including industrial, automotive, consumer electronics, and communication.
Conclusion
The TI LM35DZ/NOPB is a trusted temperature sensor that balances performance, cost, and simplicity. With its accurate measurements and wide range of applications, it continues to be a reliable solution for both consumer and industrial electronics. Whether you are building a DIY project or designing professional-grade equipment, this sensor is a dependable choice for accurate temperature monitoring.
