SN65HVD251DR: High-Speed CAN Transceiver Overview
In the fast-evolving realm of electronics, having the right components can make all the difference. One such gem in the vast sea of transceivers is the Texas Instrument SN65HVD251DR. In this guide, we'll embark on a journey to unravel the intricacies of this CAN transceiver, exploring its key features, specifications, applications, and the manufacturer's insights.
SN65HVD251DR's Overview
The SN65HVD251DR emerges as a versatile Transceiver designed for the demanding landscape of high-speed communication in Controller Area Networks (CAN). With a maximum data rate of 1Mbps, it effortlessly navigates the intricacies of data exchange. Operating within the voltage spectrum of 4.5V to 5.5V, the SN65HVD251DR strikes a balance between power efficiency and optimal performance, making it a prime selection for a wide array of electronic applications.
Key Features
1. High-Speed Data Transmission: At the heart of SN65HVD251DR lies its capability to handle a maximum data rate of 1Mbps, making it a frontrunner for applications demanding swift and efficient communication.
2. Robust Design: Crafted in adherence to ISO 11898 standards, this transceiver promises reliability and durability in challenging electronic environments.
3. Power Efficiency: With an operating voltage ranging from 4.5V to 5.5V and a maximum supply current of 65mA, the SN65HVD251DR strikes a balance between power efficiency and performance.
4. Versatile Power Modes: Equipped with both Shutdown and Standby modes, this transceiver allows for intelligent power management, optimizing energy consumption based on the system's needs.
Specifications:
Type | Parameter |
Product Category | Transceiver |
Maximum Data Rate | 1Mbps |
Number of Transceivers | 1 |
Standard Supported | ISO 11898 |
Minimum Operating Supply Voltage (V) | 4.5 |
Typical Operating Supply Voltage (V) | 5 |
Maximum Operating Supply Voltage (V) | 5.5 |
Maximum Supply Current (mA) | 65 |
Power Down Mode | Shutdown|Standby |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Supplier Temperature Grade | Extended |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 1.5(Max) |
Package Width | 3.98(Max) |
Package Length | 5(Max) |
PCB changed | 8 |
Standard Package Name | SO |
Supplier Package | SOIC |
Pin Count | 8 |
Lead Shape | Gull-wing |
Applications:
The SN65HVD251DR finds its application across a spectrum of electronic domains:
1. Automotive Systems: With its ISO 11898 compliance and robust design, the SN65HVD251DR is a reliable choice for in-vehicle networks, ensuring seamless communication in modern automotive systems.
2. Industrial Automation: In industrial settings where data integrity and speed are paramount, this transceiver proves its mettle by facilitating efficient communication between various components.
3. Embedded Systems: Embedded systems benefit from the SN65HVD251DR's power-efficient design and high-speed data transmission, enhancing overall system performance.
SN65HVD251DR's Manufacturer
Texas Instruments, a global semiconductor and electronics company, stands as a pioneering force in the technological landscape. Renowned for its commitment to innovation and excellence, Texas Instruments has played a pivotal role in shaping the electronics industry for decades. With a diverse portfolio spanning analog and digital technologies, power management, and embedded processing, Texas Instruments continues to empower engineers, designers, and innovators worldwide.
Conclusion:
It's evident that Texas Instrument SN65HVD251DR- this CAN transceiver is more than just a component – it's a catalyst for seamless communication in the world of electronics.
