Today, we're taking a deep dive into the Microchip KSZ9896CTXI, a versatile 6-port Ethernet switch that offers cutting-edge performance for a variety of networking needs. In this comprehensive article, we'll delve into the intricacies of the KSZ9896CTXI, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
The Microchip KSZ9896CTXI is a 6-port Ethernet switch designed for high-speed networking applications. With its ability to handle data rates of up to 1000 Mbps, this switch is an excellent choice for network infrastructure projects that demand reliability, scalability, and performance.
Let's delve into the standout features that make the KSZ9896CTXI a standout in the world of electronics:
· The KSZ9896CTXI supports data rates of up to 1000 Mbps, ensuring fast and efficient data transmission across networks.
· This switch supports multiple interfaces, including GMII, MII, RGMII, and RMII, providing flexibility in network design and compatibility with various devices.
· With a typical supply current of 750 mA and a single power supply type, the KSZ9896CTXI is designed for energy efficiency.
· Built-in LED drivers make it easy to monitor the switch's status and activity, aiding in network diagnostics.
· The switch supports VLANs, enabling better network segmentation and security for improved network management.
· The KSZ9896CTXI operates on supply voltages of 1.71V, 2.375V, and 3.135V, allowing it to be used in a wide range of power environments.
· With an industrial-grade operating temperature range of -40°C to 85°C, this switch is well-suited for a variety of challenging environments.
· It comes in a 128-pin TQFP EP (Thin Quad Flat Package with Exposed Pad) with package dimensions of 14mm x 14mm.
Now, let's take a closer look at the technical specifications that define the capabilities of the KSZ9896CTXI:
Type | Parameter |
Number of Primary Switch Ports | 6 |
Maximum Data Rate (MBps) | 1000 |
Typical Data Rate (MBps) | 10/100/1000 |
PHY/Transceiver Interface | GMII/MII/RGMII/RMII |
Minimum Operating Supply Voltage | 1.71V|2.375V|3.135V |
Maximum Operating Supply Voltage | 1.89V|2.625V|3.465V |
Maximum Supply Current (mA) | 750(Typ) |
Power Supply Type | Single |
Fiber Support | No |
Integrated LED Drivers | Yes |
VLAN Support | Yes |
JTAG Support | No |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Supplier Temperature Grade | Industrial |
Mounting | Surface Mount |
Package Height | 1 |
Package Width | 14 |
Package Length | 14 |
PCB changed | 128 |
Standard Package Name | QFP |
Supplier Package | TQFP EP |
Pin Count | 128 |
The KSZ9896CTXI finds use in a wide range of networking applications, including:
· Industrial Automation: Ideal for integrating into industrial network systems, the KSZ9896CTXI can handle demanding environments and data-heavy applications.
· Telecommunications: With its high-speed data rates and VLAN support, the switch is perfect for telecommunications infrastructure.
· IoT Devices: The switch's support for various interfaces makes it a strong choice for Internet of Things (IoT) devices requiring reliable network connectivity.
· Embedded Systems: The compact form factor and power-efficient design make it an excellent option for embedded systems in need of robust networking capabilities.
Microchip Technology, a global leader in the semiconductor industry, stands at the forefront of innovation, consistently pushing the boundaries of technology to create solutions that power the interconnected world. With a rich history dating back to 1989, Microchip has become synonymous with cutting-edge microcontroller and analog products. Renowned for its commitment to quality, reliability, and customer satisfaction, the company offers a comprehensive portfolio of integrated circuits and embedded solutions. Microchip's diverse range of products caters to a wide array of industries, including automotive, industrial, consumer electronics, and healthcare.
The Microchip KSZ9896CTXI is a versatile, high-performance Ethernet switch that offers a host of advanced features and a flexible interface, making it an excellent choice for a variety of networking applications. Its robust design, combined with Microchip's reputation for quality, ensures that this switch will meet the needs of even the most demanding projects.
