LPC1768FBD100K: Features, Specs & More
In today's fast-paced electronic landscape, choosing the right microcontroller can make all the difference. The LPC1768FBD100K from Freescale Semiconductor (now part of NXP Semiconductors) stands out with its robust features and versatility. This 32-bit ARM Cortex-M3 based MCU is designed to meet the demands of modern applications, ranging from industrial automation to consumer electronics. In this comprehensive article, we'll delve into the intricacies of the LPC1766FBD100K, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
LPC1768FBD100K's Overview
The LPC1768FBD100K is a powerful microcontroller unit (MCU) that integrates a 32-bit ARM Cortex-M3 core. With its efficient architecture, it is designed to perform complex tasks while maintaining low power consumption. It comes equipped with 512KB of Flash memory and a variety of I/O interfaces, making it suitable for a wide range of applications.
Key Features
Let's delve into the standout features that make the LPC1768FBD100K a standout in the world of electronics:
· Operating at a maximum frequency of 100 MHz, the LPC1768FBD100K ensures quick data processing and response times.
· With 512KB of Flash memory and 64KB of RAM, this MCU provides ample space for program storage and execution.
· The LPC1768FBD100K supports various communication protocols, including CAN, Ethernet, I2C, SPI, UART, and USB, enabling seamless integration into diverse systems.
· It features a 12-bit ADC with 8 channels and a 10-bit DAC, allowing for precise analog-to-digital conversions.
· Designed to operate in a wide temperature range (-40°C to 85°C), it is suitable for demanding industrial applications.
· With a typical operating voltage of 3.3V and a maximum power dissipation of 1500 mW, the LPC1768FBD100K is optimized for energy-efficient operation.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the LPC1768FBD100K:
Type | Parameter |
Instruction Set Architecture | RISC |
Device Core | ARM Cortex M3 |
Core Architecture | ARM |
Maximum CPU Frequency (MHz) | 100 |
Maximum Clock Rate (MHz) | 100 |
Data Bus Width (bit) | 32 |
Program Memory Type | Flash |
Program Memory Size | 512KB |
RAM Size | 64KB |
Maximum Expanded Memory Size | 1GB |
Programmability | Yes |
Interface Type | CAN/Ethernet/I2C/I2S/SPI/SSP/UART/USB |
Number of I/Os | 70 |
No. of Timers | 4 |
PWM | 1 |
Number of ADCs | Single |
ADC Channels | 8 |
ADC Resolution (bit) | 12 |
Number of DACs | Single |
DAC Resolution (bit) | 10 |
USART | 0 |
UART | 4 |
USB | 1 |
SPI | 2 |
I2C | 3 |
I2S | 1 |
CAN | 2 |
Ethernet | 1 |
Watchdog | 1 |
Parallel Master Port | No |
Real Time Clock | No |
Special Features | CAN Controller |
Minimum Operating Supply Voltage (V) | 2.4 |
Typical Operating Supply Voltage (V) | 3.3 |
Maximum Operating Supply Voltage (V) | 3.6 |
Maximum Power Dissipation (mW) | 1500 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Packaging | Tray |
Mounting | Surface Mount |
Package Height | 1.45(Max) |
Package Width | 14.1(Max) |
Package Length | 14.1(Max) |
PCB changed | 100 |
Standard Package Name | QFP |
Supplier Package | LQFP |
Pin Count | 100 |
Lead Shape | Gull-wing |
Applications
The LPC1768FBD100K is designed for a multitude of applications, including but not limited to:
· eMetering: Ideal for energy measurement and management systems.
· Lighting: Supports smart lighting solutions with advanced control capabilities.
· Industrial Networking: Facilitates robust communication in industrial automation settings.
· Alarm Systems: Enhances security systems with reliable and fast processing.
· White Goods: Used in home appliances for improved functionality and user experience.
· Motor Control: Provides precise control in motor-driven applications.
LPC1768FBD100K's Manufacturer
Freescale Semiconductor, Inc., now seamlessly integrated into NXP Semiconductors, stands as a pioneering force in the semiconductor industry. Renowned for its cutting-edge technologies, Freescale Semiconductor played a pivotal role in shaping the landscape of embedded solutions and microcontrollers. With a commitment to innovation and a rich legacy, the company has consistently delivered high-performance semiconductor solutions, catering to a diverse range of industries. Following its merger with NXP Semiconductors, a global semiconductor powerhouse, the legacy of Freescale continues to thrive, fostering advancements in automotive, industrial, and IoT applications.
Conclusion
The LPC1768FBD100K microcontroller stands out as a powerful, flexible, and efficient solution for a wide array of applications in the electronics sector. Its combination of high performance, extensive memory, and versatile interfaces makes it an excellent choice for engineers and developers looking to harness the power of embedded systems.
