STM8S003K3T6C: Features, Specs & More
In the world of electronics, microcontrollers (MCUs) play a crucial role in powering everything from consumer electronics to industrial machines. One such MCU is the STM8S003K3T6C from STMicroelectronics. In this comprehensive article, we'll delve into the intricacies of the STM8S003K3T6C, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
STM8S003K3T6C's Overview
The STM8S003K3T6C is an 8-bit microcontroller from the STM8S family, designed by STMicroelectronics. This device features an STM8 core architecture with a CISC instruction set, ensuring optimal performance for a wide range of embedded applications. It combines compact design and efficient processing capabilities, with a 16 MHz CPU frequency and 8 KB of Flash memory. With its low-voltage operation and robust connectivity options, the STM8S003K3T6C is ideal for powering everything from portable devices to home automation systems.
Key Features
Let's delve into the standout features that make the STM8S003K3T6C a standout in the world of electronics:
· 8-bit CISC Architecture: The device operates with an 8-bit data bus, making it ideal for applications that don't require high processing power but still need efficient control.
· 16 MHz Maximum CPU Frequency: This allows the MCU to handle tasks quickly without consuming excessive power.
· 8KB Flash Memory: Provides ample space for storing firmware and application code, ensuring the device is capable of handling moderately complex tasks.
· 1KB RAM: Enables effective data storage during operations.
· Low Power Consumption: With a typical operating voltage of 3.3V to 5V, the STM8S003K3T6C is suitable for battery-powered applications, offering both energy efficiency and reliability.
· Wide Operating Temperature Range: Operating from -40°C to 85°C, it's well-suited for use in a variety of environments, from industrial to automotive applications.
· Multiple I/O Options: With 28 GPIOs, this MCU supports several interfaces like I2C, SPI, and UART, allowing it to integrate seamlessly into different systems.
· Onboard ADC: A 10-bit ADC with 5 channels provides precise analog-to-digital conversions.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the STM8S003K3T6C:
Type | Parameter |
Family Name | STM8S |
Instruction Set Architecture | CISC |
Device Core | STM8 |
Core Architecture | STM8 |
Maximum CPU Frequency (MHz) | 16 |
Maximum Clock Rate (MHz) | 16 |
Data Bus Width (bit) | 8 |
Program Memory Type | Flash |
Program Memory Size | 8KB |
RAM Size | 1KB |
Maximum Expanded Memory Size | 16MB |
Programmability | Yes |
Interface Type | I2C/SPI/UART |
Number of I/Os | 28 |
No. of Timers | 7 |
Number of ADCs | 1 |
ADC Channels | 5 |
ADC Resolution (bit) | 10 |
USART | 0 |
UART | 1 |
USB | 0 |
SPI | 1 |
I2C | 1 |
I2S | 0 |
CAN | 0 |
Ethernet | 0 |
Watchdog | 2 |
Parallel Master Port | No |
Real Time Clock | Yes |
Minimum Operating Supply Voltage (V) | 2.95 |
Typical Operating Supply Voltage (V) | 3.3|5 |
Maximum Operating Supply Voltage (V) | 5.5 |
Maximum Power Dissipation (mW) | 330 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 85 |
Packaging | Tray |
Mounting | Surface Mount |
Package Height | 1.4 |
Package Width | 7 |
Package Length | 7 |
PCB changed | 32 |
Standard Package Name | QFP |
Supplier Package | LQFP |
Pin Count | 32 |
Lead Shape | Gull-wing |
Applications
Thanks to its versatility, the STM8S003K3T6C finds applications in a wide range of industries:
· Consumer Electronics: The STM8S003K3T6C is well-suited for devices such as home appliances, toys, and remote controls, where low power consumption and reliable performance are essential.
· Automotive: This MCU can be used in automotive electronics, such as control units for lighting, safety systems, and sensors.
· Industrial Control: In factory automation, this MCU can control sensors, motors, and other machinery components, where precision and reliability are critical.
· IoT Devices: With its low voltage operation and connectivity options, the STM8S003K3T6C is ideal for Internet of Things (IoT) applications that require long battery life and efficient data processing.
· Medical Devices: The device can also be used in medical equipment that requires precise control, low power consumption, and compact designs.
STM8S003K3T6C's Manufacturer
STMicroelectronics, often abbreviated as ST, is a global semiconductor manufacturer with a long-standing reputation for producing innovative and high-quality electronic components. With headquarters in Geneva, Switzerland, and a strong international presence, STMicroelectronics is a leading player in the semiconductor industry. They specialize in designing and manufacturing a wide range of semiconductor devices, including microcontrollers, sensors, power management solutions, and more. STMicroelectronics is trusted by industries worldwide, including automotive, consumer electronics, industrial, and telecommunications, for their cutting-edge technology and commitment to advancing the field of electronics.
Conclusion
The STM8S003K3T6C from STMicroelectronics offers a balanced mix of performance, power efficiency, and flexibility. Its robust set of features, including ample flash memory, multiple I/O interfaces, and wide operating voltage range, makes it suitable for a variety of embedded applications.
