ADCMP600BKSZ-R2: Features, Specs & More
When it comes to high-speed, precision analog signal processing, Analog Devices has been a trusted name among engineers and designers. One of its standout solutions is the ADCMP600BKSZ-R2, a high-performance comparator designed for demanding electronic systems. In this comprehensive article, we'll delve into the intricacies of the ADCMP600BKSZ-R2, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
ADCMP600BKSZ-R2's Manufacturer
ADCMP600BKSZ-R2's Overview
The ADCMP600BKSZ-R2 is a single-channel, high-speed comparator manufactured by Analog Devices Inc. (ADI). Engineered using ADI's XFCB2 process technology, this comparator delivers rail-to-rail input and output operation, making it a highly versatile choice for low-voltage and precision-based applications.
Key Features
Let's delve into the standout features that make the ADCMP600BKSZ-R2 a standout in the world of electronics:
· Supports rail-to-rail I/O for full-range signal handling.
· Achieves a typical propagation delay of 5ns, ensuring fast response time.
· Offers CMOS/TTL compatible output, suitable for digital interface circuits.
· Operates on a single supply voltage range from 2.5V to 5.5V.
· Exhibits a typical voltage gain of 85dB for high signal amplification.
· Maintains low input offset voltage (max 5mV at 2.5V).
· Operates over an extended industrial temperature range (-40°C to +125°C).
· Consumes a maximum supply current of only 4mA at 5.5V.
· Packaged in a compact 5-pin SC-70 form factor for space-constrained designs.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the ADCMP600BKSZ-R2:
Type | Parameter |
Manufacturer Type | High Speed Comparator |
Number of Channels per Chip | 1 |
Process Technology | XFCB2 |
Rail to Rail | Rail to Rail Input/Output |
Typical CMRR (dB) | 50(Min) |
Typical PSRR (dB) | 50(Min) |
Maximum Propagation Delay Time (ns) | 5(Typ) |
Output Type | CMOS/TTL |
Maximum Operating Supply Voltage (V) | 5.5 |
Maximum Input Offset Voltage (mV) | 5@2.5V |
Minimum Single Supply Voltage (V) | 2.5 |
Maximum Single Supply Voltage (V) | 5.5 |
Typical Voltage Gain (dB) | 85 |
Typical Voltage Gain Range (dB) | 70 to 90 |
Maximum Input Bias Current (uA) | 5@2.5V |
Maximum Supply Current (mA) | 4@5.5V |
Typical Output Current (mA) | 50(Max) |
Maximum Test Temperature (°C) | 125 |
Minimum Test Temperature (°C) | -40 |
Power Supply Type | Single |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 0.9 |
Package Width | 1.25 |
Package Length | 2 |
PCB changed | 5 |
Standard Package Name | SOT |
Supplier Package | SC-70 |
Pin Count | 5 |
Lead Shape | Gull-wing |
Applications
The ADCMP600BKSZ-R2 is engineered for high-speed signal comparison, making it ideal for a wide range of industrial and scientific applications:
· High speed instrumentation
· Clock and data signal restoration
· Logic level shifting or translation
· Pulse spectroscopy
· High speed line receivers
· Threshold detection
· Peak and zero-crossing detectors
· High speed trigger circuitry
· Pulse-width modulators
· Current/voltage-controlled oscillators
· Automatic test equipment (ATE)
ADCMP600BKSZ-R2's Manufacturer
Analog Devices, Inc. (ADI) stands as a global leader in analog and mixed-signal technology, pioneering transformative solutions since 1965. Renowned for innovation, ADI's diverse portfolio of high-performance integrated circuits spans precision amplifiers, data converters, sensors, and digital signal processing.
Conclusion
The ADCMP600BKSZ-R2 by ADI is more than just a comparator. It is a compact, high-speed solution that enables precision signal detection and response in demanding environments. With its low power consumption, wide voltage range, and industrial-grade temperature tolerance, this comparator is a valuable asset in today's fast-paced electronics applications.
