JM38510/11201BCA: Features, Specs & More
When it comes to reliable analog signal comparison in high-precision electronics, the ADI JM38510/11201BCA stands out as a robust solution. This quad differential comparator delivers rail-to-rail output, fast response times, and wide voltage tolerance, making it ideal for both military and industrial applications. In this comprehensive article, we'll delve into the intricacies of the JM38510/11201BCA, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
JM38510/11201BCA's Manufacturer
JM38510/11201BCA's Overview
The JM38510/11201BCA is a quad differential comparator manufactured by Analog Devices Inc. (ADI). Each chip contains four independent comparator channels designed to compare voltage levels and provide an open-collector output. It supports single or dual supply voltages, making it versatile for circuits that require low-voltage operation or high-voltage tolerance. Its military-grade temperature range ensures consistent performance in extreme environments.
Key Features
Let's delve into the standout features that make the JM38510/11201BCA a standout in the world of electronics:
· It has four comparator channels per chip.
· It provides rail-to-rail output for maximum signal swing.
· It operates with a typical response time of 1.3 µs.
· The response time ranges from 0.5 to 5 µs, depending on conditions.
· It features an open-collector output type for easy interfacing.
· It supports a maximum operating supply voltage of ±15V or 30V.
· The maximum input offset voltage is 3 mV at 30V.
· It allows a minimum single supply voltage of 2V.
· The maximum single supply voltage is 30V, ensuring flexibility.
· Voltage gain typically measures 106 dB, ranging from 90 to 110 dB.
· The maximum input bias current is 0.25 µA at 5V.
· Output current reaches up to 20 mA maximum.
· Quiescent current is 2 mA at 5V, minimizing power consumption.
· It supports single and dual power supply types.
· Operating temperature spans -55°C to 125°C, suitable for military-grade applications.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the JM38510/11201BCA:
Type | Parameter |
Manufacturer Type | Differential Comparator |
Number of Channels per Chip | 4 |
Rail to Rail | Rail to Rail Output |
Typical Response Time (us) | 1.3 |
Typical Response Time Range (us) | 0.5 to 5 |
Output Type | Open Collector |
Maximum Operating Supply Voltage (V) | ±15|30 |
Maximum Input Offset Voltage (mV) | 3@30V |
Minimum Single Supply Voltage (V) | 2 |
Maximum Single Supply Voltage (V) | 30 |
Maximum Dual Supply Voltage (V) | ±15 |
Typical Voltage Gain (dB) | 106.02 |
Typical Voltage Gain Range (dB) | 90 to 110 |
Maximum Input Bias Current (uA) | 0.25@5V |
Typical Output Current (mA) | 20(Max) |
Maximum Quiescent Current (mA) | 2@5V |
Power Supply Type | Single|Dual |
Minimum Operating Temperature (°C) | -55 |
Maximum Operating Temperature (°C) | 125 |
Supplier Temperature Grade | Military |
Packaging | Tube |
Mounting | Through Hole |
Package Height | 3.56(Max) |
Package Width | 7.62(Max) |
Package Length | 19.94(Max) |
PCB changed | 14 |
Standard Package Name | DIP |
Supplier Package | CDIP |
Pin Count | 14 |
Lead Shape | Through Hole |
* JM38510/11201BCA's Datasheet
Applications
The JM38510/11201BCA excels in applications where precision voltage comparison is critical. Typical use cases include:
· Signal processing in industrial automation systems.
· Analog-to-digital conversion support in embedded designs.
· Threshold detection circuits for sensors and monitoring.
· Military and aerospace electronics, requiring extreme temperature tolerance.
· Motor control and power management systems.
· Communication equipment for robust signal integrity.
JM38510/11201BCA's Manufacturer
Analog Devices, Inc. (ADI) stands as a global leader in analog and mixed-signal technology, pioneering transformative solutions since 1965. Renowned for innovation, ADI's diverse portfolio of high-performance integrated circuits spans precision amplifiers, data converters, sensors, and digital signal processing.
Conclusion
The ADI JM38510/11201BCA is a versatile, high-performance quad differential comparator suitable for both industrial and military applications. Its rail-to-rail output, fast response, and wide operating voltage range make it ideal for precise signal comparison and threshold detection. With robust specifications and trusted ADI quality, it remains a top choice for engineers and electronics designers seeking reliable performance in critical circuits.
