TLE49631MXTSA1: Features, Specs & More
The Infineon TLE49631MXTSA1 is a highly reliable Hall Effect sensor designed for automotive applications. This 3-pin SOT-23 surface-mount device provides precise magnetic detection with a low supply current of just 5 mA. It meets the stringent AEC-Q100 automotive standard, making it suitable for harsh environments. This sensor combines robust design, energy efficiency, and excellent magnetic sensitivity. It is ideal for applications where accurate position or speed detection is required. In this comprehensive article, we'll delve into the intricacies of the TLE49631MXTSA1, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
TLE49631MXTSA1's Overview
The Infineon TLE49631MXTSA1 is a highly reliable Hall Effect sensor designed for automotive and industrial applications. It operates as a magnetic latch sensor and delivers consistent performance across a wide voltage range. This sensor is known for its durability, precision, and compliance with the automotive-grade AEC-Q100 standard. Its compact 3-pin SOT-23 package makes it ideal for modern surface-mount PCB designs.
Key Features
Let's delve into the standout features that make the TLE49631MXTSA1 a standout in the world of electronics:
· The sensor operates with a supply voltage ranging from 3V to 5.5V.
· It has a maximum output current of 5mA, suitable for direct interfacing with microcontrollers.
· The typical output fall time is extremely fast at 0.24 microseconds.
· It features a magnetic latch type for stable switching behavior.
· The sensor can operate in temperatures from -40°C to 170°C, ensuring reliability in extreme conditions.
· The package is SOT-23 3-pin, with a gull-wing lead shape for surface-mount applications.
· It supports tape and reel packaging, facilitating automated assembly processes.
· Magnetic sensor points include a minimum release point of -35 Gs, maximum operating point of 35 Gs, and typical hysteresis of 40 Gs.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the TLE49631MXTSA1:
Type | Parameter |
Magnetic Type | Latch |
Module/IC Classification | IC |
Minimum Magnetic Sensor Release Point (Gs) | -35 |
Typical Magnetic Sensor Hysteresis (Gs) | 40 |
Maximum Magnetic Sensor Operating Point (Gs) | 35 |
Typical Output Fall Time (us) | 0.24 |
Maximum Output Current (mA) | 5 |
Minimum Operating Supply Voltage (V) | 3 |
Typical Operating Supply Voltage (V) | 3.3|5 |
Maximum Operating Supply Voltage (V) | 5.5 |
Maximum Supply Current (uA) | 2500 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 170 |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 1(Max) |
Package Width | 1.3 |
Package Length | 2.9 |
PCB changed | 3 |
Standard Package Name | SOT |
Supplier Package | SOT-23 |
Pin Count | 3 |
Lead Shape | Gull-wing |
Applications
The TLE49631MXTSA1 is widely used in automotive and industrial electronics. Key applications include:
· Throttle position sensing in automotive engines.
· Wheel speed detection for ABS and traction control systems.
· Rotational position sensing in motors and actuators.
· Magnetic switches for industrial automation.
· Contactless switching in electronic devices.
Its high temperature tolerance and small footprint make it particularly suitable for embedded and compact systems.
TLE49631MXTSA1's Manufacturer
Established in 1999, Infineon Technologies has emerged as a global leader in semiconductor solutions, pioneering innovations that power various industries worldwide. Headquartered in Neubiberg, Germany, the company has played a pivotal role in shaping the landscape of modern electronics. Infineon specializes in designing and manufacturing advanced semiconductor technologies, encompassing power management, automotive electronics, industrial applications, and security solutions.
Conclusion
The Infineon TLE49631MXTSA1 is a versatile and reliable Hall Effect sensor ideal for automotive and industrial applications. Its small SOT-23 package, wide voltage range, and high temperature tolerance make it an excellent choice for engineers designing precision magnetic field detection systems. With fast output response and low power consumption, it stands out as a robust solution for modern electronics.
