Can a Thermistor Be Connected in Series with a Resistor?
In electronic circuit design, thermistors are widely used in applications such as temperature detection, overcurrent protection, and temperature compensation. Many engineers and electronics enthusiasts often ask: Can a thermistor be connected in series with a standard resistor? The answer is yes. Connecting a thermistor in series with a resistor can not only adjust the overall resistance value but also help build temperature detection voltage divider circuits and limit startup current. However, since these two components have different operating characteristics, factors such as resistance matching, temperature response, and power handling capability must be carefully considered during practical applications to ensure stable circuit operation.
Catalog
II. Key Factors When Connecting a Thermistor and a Resistor in Series
III. Common Applications of Thermistors Connected in Series
I. What Is a Thermistor?
A thermistor is a temperature-sensitive resistor whose resistance value changes according to variations in ambient temperature. Unlike a standard fixed resistor, a thermistor uses the temperature characteristics of its material to achieve resistance changes, making it widely used in temperature measurement, temperature control, and circuit protection applications.
Based on their temperature coefficients, thermistors are mainly divided into two types: NTC thermistors and PTC thermistors.
An NTC thermistor (Negative Temperature Coefficient Thermistor) has the characteristic that its resistance decreases as temperature rises. It is commonly used in temperature sensors, power supply inrush current suppression, and battery management systems.
A PTC thermistor (Positive Temperature Coefficient Thermistor) has the characteristic that its resistance increases as temperature rises. It is commonly used for overcurrent protection, resettable fuses, and heating control applications.
A standard resistor, on the other hand, is an electronic component with a relatively fixed resistance value and is mainly used for current limiting, voltage division, and bias adjustment in circuits. Since a thermistor changes its resistance with temperature while a standard resistor remains relatively stable, connecting them in series creates a composite resistance network with temperature response capabilities.
II. Key Factors When Connecting a Thermistor and a Resistor in Series
1. Resistance Matching
When connecting a thermistor and a standard resistor in series, the first consideration is whether the resistance ratio between the two components is appropriate. In a series circuit, the total resistance equals the sum of the two component values, meaning the resistor value directly affects the operating range of the entire circuit.
For example, in an NTC thermistor temperature detection circuit, a fixed resistor with a resistance value close to the thermistor’s nominal resistance is usually selected to achieve a more noticeable voltage change and improve temperature detection accuracy. If the fixed resistor value is too high, it may reduce the thermistor’s response to temperature changes. If the resistance value is too low, the adjustment range of the circuit may become insufficient.
Therefore, during circuit design, the series resistor parameters should be selected according to the operating temperature range, detection accuracy requirements, and specific circuit conditions.
2. Temperature Response Characteristics
The most important feature of a thermistor is that its resistance changes with temperature. Therefore, when using it in series with a resistor, the temperature response curve must be considered to ensure it meets the design requirements.
For an NTC thermistor, its resistance decreases as temperature increases, causing the total resistance of the series circuit to change accordingly. When used in a temperature detection circuit, the thermistor must provide sufficient resistance variation within the target temperature range so that the controller can accurately detect temperature changes.
At the same time, different thermistor models have different B values, nominal resistance values, and operating temperature ranges. Even thermistors with the same resistance value may have different temperature response characteristics. Therefore, when selecting a thermistor, engineers should not only consider the initial resistance value but also review the complete temperature characteristic specifications.
3. Rated Power and Safe Operating Range
When a thermistor and a standard resistor are connected in series, the same current flows through both components, so the power handling capability of each component must be considered.
The standard resistor must meet the required power rating to prevent excessive temperature rise caused by long-term operation. A thermistor also has a maximum power limitation. If the current is too high, self-heating may occur, causing further resistance changes and potentially damaging the component.
Especially in applications such as power input protection and inrush current limiting, NTC thermistors often need to withstand large transient currents. Therefore, the selected component must meet the requirements of circuit voltage, current, and ambient temperature conditions.
III. Common Applications of Thermistors Connected in Series
Thermistors connected in series with resistors are widely used in electronic applications. In temperature detection circuits, these components are often combined to form a voltage divider network, converting temperature changes into voltage signals that can be read by microcontrollers or sensor ICs.
In power management applications, an NTC thermistor connected in series with a resistor can be used to limit startup current, reduce the surge current generated when electronic devices are powered on, and improve system reliability.
In addition, thermistor series circuits are also used for temperature compensation and overheating protection in battery charging and discharging systems, LED drivers, industrial control equipment, and consumer electronic products.
IV. Conclusion
A thermistor can be connected in series with a standard resistor, and this configuration has significant applications in the electronic components industry. However, because a thermistor has the unique characteristic of changing resistance with temperature, circuit designers must carefully consider factors such as resistance matching, temperature response characteristics, and rated power when designing series circuits.
