ADCMP600BKSZ-REEL7: Features, Specs & More
In modern electronic systems, speed, accuracy, and board space often define design success. The ADI ADCMP600BKSZ-REEL7 addresses these demands by combining fast response times with rail-to-rail operation in an ultra-compact package. Designed for precision signal comparison, this high-speed comparator is widely used in timing-critical and low-voltage applications where consistent performance matters. In this comprehensive article, we'll delve into the intricacies of the ADCMP600BKSZ-REEL7, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
Catalog
ADCMP600BKSZ-REEL7's Manufacturer
ADCMP600BKSZ-REEL7's Overview
The ADCMP600BKSZ-REEL7 is a high-speed single-channel comparator manufactured by Analog Devices, Inc. It compares two analog input voltages and produces a digital-level output based on their relative magnitude. The device supports rail-to-rail input and output operation, which allows it to function effectively across the full supply voltage range. It operates from a single power supply, simplifying power management in compact electronic systems.
Key Features
Let's delve into the standout features that make the ADCMP600BKSZ-REEL7 a standout in the world of electronics:
· The ADCMP600BKSZ-REEL7 supports rail-to-rail input and output operation.
· The device delivers a typical propagation delay of 5 nanoseconds.
· The comparator operates from a single supply voltage ranging from 2.5 volts to 5.5 volts.
· The output stage is compatible with CMOS and TTL logic levels.
· The device provides a typical voltage gain of 85 decibels.
· The comparator features low input offset voltage at typical operating conditions.
· The package is optimized for surface-mount applications with minimal PCB footprint.
Specifications
Now, let's take a closer look at the technical specifications that define the capabilities of the ADCMP600BKSZ-REEL7:
Type | Parameter |
Manufacturer Type | High Speed Comparator |
Number of Channels per Chip | 1 |
Rail to Rail | Rail to Rail Input/Output |
Process Technology | <2.5um |
Typical CMRR (dB) | 50(Min) |
Typical PSRR (dB) | 50(Min) |
Maximum Propagation Delay Time (ns) | 5(Typ) |
Output Type | CMOS/TTL |
Maximum Operating Supply Voltage (V) | 5.5 |
Maximum Input Offset Voltage (mV) | 5@2.5V |
Minimum Single Supply Voltage (V) | 2.5 |
Maximum Single Supply Voltage (V) | 5.5 |
Typical Voltage Gain (dB) | 85 |
Typical Voltage Gain Range (dB) | 70 to 90 |
Maximum Input Bias Current (uA) | 5@2.5V |
Maximum Supply Current (mA) | 4@5.5V |
Typical Output Current (mA) | 50(Max) |
Maximum Test Temperature (°C) | 125 |
Minimum Test Temperature (°C) | -40 |
Power Supply Type | Single |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Temperature (°C) | 125 |
Packaging | Tape and Reel |
Mounting | Surface Mount |
Package Height | 0.9 mm |
Package Width | 1.25 mm |
Package Length | 2 mm |
PCB changed | 5 |
Standard Package Name | SOT |
Supplier Package | SC-70 |
Pin Count | 5 |
Lead Shape | Gull-wing |
* ADCMP600BKSZ-REEL7's Datasheet
Applications
The ADCMP600BKSZ-REEL7 is commonly used in applications where fast and precise voltage comparison is required.
· High speed threshold detection circuits
· Portable and battery-powered electronics
· Signal conditioning for ADC front ends
· Zero-crossing detectors
· Clock and timing circuits
· Industrial control and monitoring systems
ADCMP600BKSZ-REEL7's Manufacturer
Analog Devices, Inc. (ADI) stands as a global leader in analog and mixed-signal technology, pioneering transformative solutions since 1965. Renowned for innovation, ADI's diverse portfolio of high-performance integrated circuits spans precision amplifiers, data converters, sensors, and digital signal processing.
Conclusion
The ADI ADCMP600BKSZ-REEL7 is a reliable high speed comparator that delivers excellent performance in a compact footprint. Its low propagation delay, wide supply range, and rail-to-rail I/O make it an ideal choice for precision and high speed electronic designs. For engineers seeking a balance of speed, accuracy, and efficiency, this comparator stands out as a practical and proven solution in modern circuit applications.
